UFO E2 Submersible Fitting

A small submersible eyeball fitting manufactured from stainless steel with a clear focusing lens.
Available with a backnut for fixing through a panel or with a backbox, for fitting into Durapipe 1 1/4" class C pool pipe, for more accurate and easier installation.
Suitable for installation in constant immersion settings such as swimming pools, ponds and water features.
TECHNICAL INFORMATION
Lens13mm (0.51") clear focusing lens
Focus Range20° - 40°
Material316 stainless steel
Available FinishesNatural stainless steel
Weight142.4g (0.31lb) (including back box)
Ferrule SizeM8 (M10 to special order)
Fiber Sizes 2mm (0.08") to 6mm (0.24") diameter (8mm max. with M10)
Ordering CodesUFO E2-SS-N-M8
UFO E2-SS-N-M10

Note: M10 version may be subject to extended lead time and cost.

Product Datasheet
Installation Guide
